Fluid Connections Sample Kit

Please find below the list of components contained within our Fluid Connections Sample Kit.

Our kits are designed to be a sample of the typical parts contained within a particular type of product such as fluid connections.

...

     E-MF-AP-21E21E21E-U-NAT-YY Connector with 200 series
     Barb, 3/16’’ (4.8mm)

     The West Group - Barbed Check Valve Range View Connectors

     E-C-2015-0010 - Check Valve, with tubing to Male Locking
     Luer

     The West Group - Barbed Check Valve Range View Luers

     E-F-171171Male Luer Integral Lock Ring to 5/32” 500 Series
     Barb, Natural Polypropylene

      The West Group - Barbed Check Valve RangeView Luers

     E-N-NY-0A0A-B-SA-BD - Metal Needle Valve

     The West Group - Barbed Check Valve Range View Valves

     E-F-171500Female Luer x 3/32” Hose Barb

     The West Group - Barbed Check Valve Range View Luers

     WG14027Shut Off Valves

     The West Group - Barbed Check Valve Range View Valves

     E-T-160025Pump Tubing. Flexible tubing 1/8 ID
     X 1/4 OD

     The West Group - Barbed Check Valve Range View Tubing

     E-T-160020Flexible Kynar Lined Tubing 1/8 ID
     X 1/4 OD

     The West Group - Barbed Check Valve Range View Tubing

     E-V-2015-0016Stopcock Polycarbonate

     The West Group - Barbed Check Valve Range View Valves

     E-V-180433 - 1-Way Stopcock, Male Luer x Male Luer, Kynar,
     Viton

     The West Group - Barbed Check Valve Range View Luers

     E-M-18001420mm Filter Male/Female Luer Lock, ABS Body,
     0.22 Micron Hydrophobic PTFE

     The West Group - Barbed Check Valve Range View Luers

     E-F-PP-2A1ZB-V-SW-EL-USSwivel elbow, 10-32 UNF male x
     1/8” hose barb

     The West Group - Barbed Check Valve Range View Fittings

      F516-NP-B3UNF1-NBR1/8” Easy Barb x 10-32 UNF
      Male

      The West Group - Barbed Check Valve Range View Fittings

      E-Q-1603071/16” flow acetal In-Line Socket,
      NV

      The West Group - Barbed Check Valve Range View Couplings

      E-T-180002In-Line Plug, NV, 1/16”
      HB

      The West Group - Barbed Check Valve Range View Couplings

      E-M-18003920mm Disc Capsule with Stainless Steel 25
      Micron Filter, Polypropylene Bodied

      The West Group - Barbed Check Valve Range View Filters

      E-Q-1604691/8” Flow polypropylene In-Line Socket, NV,
      Molded Almond Colour

      The West Group - Barbed Check Valve Range View Couplings

      E-Q-160488 - 1/8” flow polypropylene In-Line Plug, NV,
      Moulded Almond Colour

      The West Group - Barbed Check Valve Range View Couplings

      E-Q-160626 - 1/8” Flow Chrome Brass In-Line Plug,
      NV

      The West Group - Barbed Check Valve Range View Couplings

      E-Q-160115 - Acetal/Nylon Shut-Off Tube Fitting, Quick
      Coupling, 1/8” Barbed Male

      The West Group - Barbed Check Valve Range View Couplings

     E-Q-160066 - Triggering Open-Flow Female 1/8” Barb
      White

      The West Group - Barbed Check Valve Range View Couplings

      E-QK-NY-1CQM-B-OF-SW - Rotating Open-Flow Male 1/8”
      Barb Red/White

      The West Group - Barbed Check Valve Range View Couplings

      E-Q-160699 - Triggering Open-Flow Female 1/8” Barb
      Black

      The West Group - Barbed Check Valve Range View Couplings

      E-Q-160700 - 1/4 NPT Male Threaded Shut Off Female Light
      Blue

      The West Group - Barbed Check Valve Range View Couplings

      E-Q-160701 - Triggering Open-Flow Male 1/4” Barb
      Black

      The West Group - Barbed Check Valve Range View Couplings

     E-C-PS-1C1C-C-0.03-LF - Mini Polysulfone Check Valve, 1/8”
     hose barb, <0.8” H20 cracking pressure

     The West Group - Barbed Check Valve Range View Check Valves

      E-T-180004 - Grey Silcryn Jacket and 5 Core 6mm OD 95A
      Polyurethane

      The West Group - Barbed Check Valve Range View Tubing

      E-TPU-18-066-6MCR-30 - Multi-Coloured Ribbon
      Tubing

      The West Group - Barbed Check Valve Range View Tubing

     E-O-PS-1C1C-U-0-004 - 0.004” Orifice Restrictor,
     Polysulfone

     The West Group - Barbed Check Valve Range View Check Valves

     E-C-PS1C1C-C-0.03 - Mini Polysulfone Check Valve

     The West Group - Barbed Check Valve Range View Check Valves

      E-C-180182 - 1/4 x 1/4 Barb In-Line Standard Check Valve,
      Polycarbonate, Silicone

      The West Group - Barbed Check Valve Range View Check Valves
