Insulated Crimp-on Connector for Spade Terminal Style Solenoid Valves - ESV Series

Insulated Crimp-on Connector for Spade Terminal Style Solenoid Valves - ESV Series

E-V-180180

Insulated Crimp-on Connector for Spade Terminal Style Solenoid Valves - ESV Series

Delivery date will be confirmed after order is placed.

Order will not be fulfilled immediately due to stock availability, payment taken when order placed. Contact us for further information on expedited delivery.

Insulated Crimp-on Connector for Spade Terminal Style Solenoid Valves - ESV Series
$18.04
Add To Wishlist
Quantity
Price

10 - 24

$18.04

25 - 49

$17.09

50

$16.14

Looking to purchase a large quantity? Click here
X

Bulk price quote request

Product Details

E-V-180180

Insulated Crimp-on Connector for Spade Terminal Style Solenoid Valves - ESV Series

Personal Details

Please enter a CompanyPlease enter a valid Company, the maximum length is 50 characters

Please select a valid Title, the maximum length is 12 characters.

Please enter a First NamePlease enter a valid First Name, the maximum length is 50 characters.

Please enter a Last NamePlease enter a valid Last Name, the maximum length is 50 characters.

Contact Details

Please select a valid Contact Number, the maximum length is 30 charactersPlease enter a valid Contact Number consisting only of the following characters & spaces ( ) + 0 1 2 3 4 5 6 7 8 9

Please enter a valid Email AddressPlease enter a valid Email AddressThe Email Address entered is already registered, please sign in with the Email Address or enter a different one

Please enter a QuantityPlease enter a valid number between 10 and 999999

Please confirm you are not a robot.
We have been unable to verify your identity, please confirm you are not a robot.

Description Insulated Crimp-on Connector for Spade Terminal Style Solenoid Valves - ESV Series

Extended Description Insulated crimp-on spade lug connector to suit spade terminal style MU series analytical and oxygen clean solenoid valves

Mounting Style In-Line

Media Temperature 0 to 82°C (32 to 180°F) (Limited by associated Valves)

Non-Wetted Materials Tin Plated Brass, Nylon

Operating Temperature 0°C – 82°C (32°F – 180°F) (Limited by associated Valves)

Cleanroom Manufactured Uncontrolled Environment

Item Weight 0.0005Kg (0.5g)

ROHS Compliant Yes

REACH Compliant Yes

Other Technical Data For further information please contact us on +44 (0)2392 266031

Disclaimer: All information has been carefully collated and presented, however, The West Group Ltd cannot accept responsibility for incorrect or misprinted information

3D model (IGS)
